ResMed Lumis 150 VPAP ST

Technical specifications

Modes

CPAP, S, T, ST with optional iBR, PAC, iVAPS with iBR and optional AutoEPAP

Operating pressure range

2–25 cm H2O (2–25 hPa) in S, T, ST, PAC and iVAPS modes

4–20 cm H2O (4–20 hPa) in CPAP mode

Sound pressure level

26.6 dBA with uncertainty of 2 dBA as measured according to ISO 17510-1:2009 (CPAP mode)

Dimensions (H x W x D)

116 mm x 205 mm x 150 mm (Device only)

116 mm x 255 mm x 150 mm (Device with HumidAir humidifier)

Weight

1106 g (Device only)

1268 g (Device with HumidAir humidifier)

90W power supply unit

Input range: 100–240V, 50–60Hz, 57VA (typical power consumption) 108VA (peak power consumption)

Operating temperature/humidity/altitude

+5°C to +35°C/ 10–95% relative humidity, non-condensing/ Sea level to 2,591 m; air pressure range 1013 hPa to 738 hPa

Storage and transport temperature/humidity

-20°C to +60°C/ 5–95% relative humidity, non-condensing

Housing construction

Flame retardant engineering thermoplastic

Supplemental oxygen

Recommended maximum flow: 15 L/min

(CPAP, S, T, ST, PAC); 4 L/min (iVAPS)

Standard air filter

Polyester non-woven fibre

Tubing

SlimLine™ and ClimateLineAir (15 mm); Standard (19 mm)

Air outlet

22 mm air outlet complies with ISO 5356-1:2004

Electromagnetic compatibility

Requirements (EMC) according to IEC60601-1-2:2007 for residential, commercial, and light industry environments

Aircraft use

ResMed confirms that device meets the Federal Aviation Administration (FAA) requirements

(RTCA/DO-160, section 21, category M) for all phases of air travel

IEC 60601-1: 2006 classification

Class II (double insulation), Type BF Ingress protection IP22
